Fitting Guide & Templates

Download PDF Templates

Please review the Viewing Distances Guide for the product before installation. You can also download your Free Template to assist with sign placement.

Download the A3 fitting guide template
Download the A4 fitting guide template
Download the A5 fitting guide template


Vinyl self-adhesive

  1. Select the position to adhere your sign, (remember to consider the viewing distance and height of the sign) See Viewing Distances Guide.
  2. Ensure surface is free from Grit, Dirt and Dust.
  3. Clean the fixing surface to remove Grease, Grime and Oxides.
  4. Fitting your sign, when positioned use firm strokes from the centre of the sign radiating in straight lines to the outer edge. Ensuring removal of all air.

Mounted Signs. Self Adhesive fixing

  1. Self adhesive foam fixing pads are supplied internal use only.
  2. We recommend screw fixing for all signs A5 size and larger.

Mounted Signs. Screw fixing

  1. Select the position to fix your sign, (remember to consider the viewing distance and height of the sign) See Viewing Distances Guide.
  2. Using your Free template mark the position of the holes required on the fixing surface. Choice of two vertical holes RED option, two horizontal holes BLUE option or four corner holes GREEN option.
  3. Drill 6mm holes as required, insert wall fixing plugs. Fix sign using the screws remembering to put the screw through the screw head cover before tightening the screws.
  4. Self Adhesive Pads are included with your mounted sign

Fixing Packs

SKU. JPS-ACC-105 (FP2) 2x wall plugs, 2x #4 x 40mm PZ CS screws, 2x Caps for screw head covers 14mmx4mm White

SKU. JPS-ACC-106 (FP4) 4x wall plugs, 4x #4 x 40mm PZ CS screws, 4x Caps for screw head covers 14mmx4mm White

SKU. JPS-ACC-107 (FP6) 6x wall plugs, 6x #4 x 40mm PZ CS screws, 6x Caps for screw head covers 14mmx4mm White
